    Rexroth Hydraulic Axial Piston Variable Pump A4FO250/31R-PPB25N00 Piston Pump Motor A4FO22 A4FO28 A4FO40

    Ask Lasest Price
    Brand Name : REXROTH
    Model Number : A4FO250/31R-PPB25N00 A4FO500/30R-VPH25N00
    Price : NIGOTIATION
    Payment Terms : T/T
    Supply Ability : 1000/month
    Delivery Time : 15 work days
    • Product Details
    • Company Profile

    Rexroth Hydraulic Axial Piston Variable Pump A4FO250/31R-PPB25N00 Piston Pump Motor A4FO22 A4FO28 A4FO40

    Rexroth Hydraulic Axial Piston Variable Pump A4FO250/31R-PPB25N00 Hydraulic Motor Piston Pump Motor A4FO22 A4FO28 A4FO40

    Model no.
    A4FO250
    Type
    Plunger Pump
    After-Sales Service
    Online Support
    Pump Type
    Piston Pump
    Warranty
    1 Year
    Weight
    80kg
    Model
    A4fo250
    Brand Name
    Rexroth
    Material
    Material
    Straight Shaft Swashplate Piston Type
    Pressureoil
    Pressure
    High Pressure
    Trademark
    Rexroth
    Transport Packaging
    Wooden Box
    Characteristics
    30*30*50

    Product Number Specifiions Working Pressure Characteristic
    A4FO 16,22,28,40,71,
    125,250,500
    Common pressure: 40Mpa,
    Peak pressure:45Mpa.
    A4FO Axial Plunger Quantitative Pump with Swashplate Structure for Hydraulic Driving in Open Loop;
    - Flow is proportional to driving speed and displacement;
    - Excellent oil absorption performance;
    - Very low noise;
    - Long service life;
    - Allow the use of combined pumps;
    - Axle drive for assembling other pumps.
    Safety instructions
    1, During start-up and operation, the pump shell must be filled with hydraulic oil (injected into the shell cavity). It must be started at low speed without load until the system is completely emptied;
    System design, installation and commissioning need to be performed by trained technicians and distributors;
    2, When parked for a long time, the oil can be discharged from the shell through the working pipeline. When restarting, enough oil should be injected into the shell;
    3,The minimum oil suction pressure of the nozzle S shall not be reduced to less than 0.8 bar.
    Installation loion
    4,The axis is horizontal to the bottom. When mounting on the tank, the installation position of "axis level, suction port facing bottom" is not allowed;
    Installation below tank level;
    Pump position below minimum oil level in tank (standard)
    5,Fill the axial plunger pump before starting through the highest position of the shell outlet.
    Suggestion: Filling suction pipeline
    Low-speed running pump (ignition speed) until the pump system is fully filled;
    The lowest immersion depth of suction or drain pipelines in the tank is 200 mm (relative to the lowest oil level in the tank);
    6,Installation position higher than tank level
    Pumps mounted above the lowest oil level in the tank
    Installation position below tank level
    7,It is not allowed to use the installation position of "shaft against the top" and "axis level, oil suction port at the bottom" (when shutdown, the pump shell discharges oil through oil suction pipeline).
    Tightening Torque
    1,All the tightening torques listed in this sample are maximum values and should not exceed these values (maximum of internal threads in castings). Please follow the information provided by the manufacturer regarding the maximum allowable fastening torque of the fittings used.
    · For DIN 13-compliant fastening screws, it is recommended that the allowable tightening torque be checked according to VDI 2230 (promulgated in 2003) in all s.;
    2,The housing, especially the coil, may be particularly hot during or shortly after the operation of the pump. Please take appropriate safety measures (for example, wear protective clothing).
    - All data and information provided with the product must be complied with;
    3,All data and information provided with the product must be complied with..
    Note
    1,Maximum permissible pipette length Hmax = 800 mm;
    2,Minimum Permissible Pressure of Oil Nozzle S (Minimum Oil Absorption Pressure).

    Rexroth Hydraulic Axial Piston Variable Pump A4FO250/31R-PPB25N00 Piston Pump Motor A4FO22 A4FO28 A4FO40Rexroth Hydraulic Axial Piston Variable Pump A4FO250/31R-PPB25N00 Piston Pump Motor A4FO22 A4FO28 A4FO40Rexroth Hydraulic Axial Piston Variable Pump A4FO250/31R-PPB25N00 Piston Pump Motor A4FO22 A4FO28 A4FO40

    R902410708 A A4F O 250 /30L-PPB25N00
    R902471464 A A4F O 250 /30L-PZB25N00
    R902518608 A A4F O 250 /30R-FPB25U35
    R902518593 A A4F O 250 /30R-FZB25N00
    R902433990 A A4F O 250 /30R-PPB25K34
    R902413431 A A4F O 250 /30R-PPB25K35
    R902409010 A A4F O 250 /30R-PPB25N00
    R902547288 A A4F O 250 /30R-PPB25U33
    R902495355 A A4F O 250 /30R-PPB25U34
    R902563524 A A4F O 250 /30R-PPB25U35
    R902543419 A A4F O 250 /30R-PPB25UB5
    R902488853 A A4F O 250 /30R-PZB25K34
    R902452732 A A4F O 250 /30R-PZB25K35
    R902407892 A A4F O 250 /30R-PZB25KB2
    R902405596 A A4F O 250 /30R-PZB25N00
    R902567145 A A4F O 250 /30R-PZB25U33
    R902514305 A A4F O 250 /30R-PZB25UB2
    R902422014 A A4F O 250 /30R-VPB25K02
    R910999372 A A4F O 250 /30R-VPB25N00
    R902551464 A A4F O 250 /30R-VZB25N00
    R902551465 A A4F O 250 /30R-VZB25U35
    R900241006 A4FO 250/30L-PPB25N00
    R910992937 AE A4F O 250 /30R-KPB13N00
    R902423149 AE A4F O 250 /30R-PPB25K02
    R902448613 AE A4F O 250 /30R-PPB25N00
    R902451737 AE A4F O 250 /30R-VPB25N00
    R902558147 AH A4F O 250 /30L-PPB25N00
    R902484892 AH A4F O 250 /30L-PZB25U24
    R902485221 AH A4F O 250 /30L-PZB25U99
    R902412100 AH A4F O 250 /30R-PPB25N00
    R902516610 AH A4F O 250 /30R-PPB25U35
    R902516609 AH A4F O 250 /30R-PZB25N00
    R902485213 AH A4F O 250 /30R-PZB25U24
    R902476612 AH A4F O 250 /30R-PZB25U35
    R902476613 AH A4F O 250 /30R-PZB25U99
    R902556367 AH A4F O 250 /30R-VPB25U34
    R902466136 AH A4F O 250 /30R-VZB25U99
    R902431603 AL A4F O 250 /30L-PPB25N00
    R902517589 AL A4FO250 /30R-PZB25N00
    R902474137 A A4F O 180 /30L-PPB25N00
    R902513374 A A4F O 180 /30L-PPB25U01
    R902518246 A A4F O 180 /30L-PPB25U01 -S2075
    R902474136 A A4F O 180 /30R-PPB25N00
    R902486858 A A4FO180 /30R-PZB25KB5
    R902466133 A A4F O 125 /30L-PPB25K33
    R902419396 A A4F O 125 /30L-PPB25N00
    R902418008 A A4F O 125 /30L-PZB25N00
    R902549472 A A4F O 125 /30L-PZB25N00 C
    R902514220 A A4F O 125 /30R-FPB25N00
    R902434690 A A4F O 125 /30R-FZB25K04
    R902413046 A A4F O 125 /30R-PPB25K24
    R902466134 A A4F O 125 /30R-PPB25K33
    R902416428 A A4F O 125 /30R-PPB25K34
    R902488327 A A4F O 125 /30R-PPB25K34
    R902420734 A A4F O 125 /30R-PPB25N00
    R902534570 A A4F O 125 /30R-PZB25I70
    R902461866 A A4F O 125 /30R-PZB25K33 -S1659
    R902473774 A A4F O 125 /30R-PZB25KB2
    R902488326 A A4F O 125 /30R-PZB25N00
    R902416433 A A4F O 125 /30R-PZB25N00
    R902534558 A A4F O 125 /30R-PZB25U34
    R902551550 A A4F O 125 /30R-PZB25U68
    R902548845 A A4F O 125 /30R-VPB25N00
    R902422096 AE A4F O 125 /30R-PPB25N00
    R902446140 AL A4FO125 /30R-PPB25N00
    R902426845 A A4F O 71 /10L-PPB25N00
    R902538910 A A4F O 71 /10L-PZB25K33
    R902428880 A A4F O 71 /10L-PZB25N00
    R902545509 A A4F O 71 /10L-PZB25N00 C
    R902448477 A A4F O 71 /10L-VPB25N00
    R902425817 A A4F O 71 /10R-PPB25C09
    R902433176 A A4F O 71 /10R-PPB25K31
    R902565650 A A4F O 71 /10R-PPB25K52
    R902425821 A A4F O 71 /10R-PPB25K57
    R902486128 A A4F O 71 /10R-PPB25K68
    R902419199 A A4F O 71 /10R-PPB25N00
    R902438486 A A4F O 71 /10R-PZB25K33
    R902519287 A A4F O 71 /10R-PZB25K68
    R902565575 A A4F O 71 /10R-PZB25KB3
    R902566827 A A4F O 71 /10R-PZB25KB3 -SO149
    R902426161 A A4F O 71 /10R-PZB25N00
    R902425394 A A4F O 71 /10R-VPB25K33
    R902426064 A A4F O 71 /10R-VPB25N00
    R902462481 A A4F O 71 /10R-VZB25K99
    R902543415 A A4F O 71 /10R-VZB25KB8
    R902543406 A A4F O 71 /10R-VZB25KE1
    R902425392 A A4F O 71 /10R-VZB25N00
    R902444067 AE A4F O 71 /10R-PPB25N00
    R902546229 AH A4F O 71 /10R-VZB225K99 -S219
    R902551532 AH A4F O 71 /10R-VZB25K99 -S2196
    R902520509 AL A4F O 71 /10R-PZB25K68
    R902462534 AL A4FO71 /10R-VZB25K99
    R902039558 A4FO40/32L-NTC12K01
    R902039557 A4FO40/32R-NTC12K01
    R902231380 A4FO40/32R-NTC12K01-S
    R902239833 A4FO40/32R-NTC12K01-S
    R902227660 A4FO40/32R-NTC12K01-S
    R902105159 A4FO40/32R-NTC12K02
    R902094020 A4FO40/32R-NTC12N00-S
